Technical Specifications | |
| Features | |
| Service Policies | |
| Rapid development and deployment of customized policies | - Multi-tiered routing (no limit on number of tiers)
- Multiple numbering plans (no limit): international, national, and private
- Advanced call screening
- Re-routing/route advance
- Virtual Private Networks (VPN) support
- Combination of TDM and IP routes
|
| Over 160 routing/screening parameters | - Signaling attributes
- System attributes (for example, trunk group parameters)
- Dynamic attributes (for example, Time of Day, ASR)
|
Other Service Policies | - Announcements, account codes, personal pin, security pin, triggers, and authentication
|
| Security | - Provides security and NAT functions for signaling and media planes
- Offers defenses against Denial of Service (DoS) and other IP layer attacks
- Supports all H.323 and SIP peering traffic
- Network-wide scalability
- Resides in the network core or in distributed Points Of Presence (POP) as per service provider needs
- Advanced provisioning and enforcement of security policies
|
SS7
(IMS/TISPAN equivalence; SGF) | - Termination of SS7 MTP, ISUP, TCAP
- Telcordia tested
- VeriSign (Illuminet) certified
- Multi-National SS7 support
- Support for ANSI, ITU, ETSI, and dozens of country-specific variants
- Programmable signaling framework (data-driven variant support)
- Support for up to 126 A-links/E-Links/F-links per DSG
|
M3UA
| - Supports M3UA adaptation layers defined within the SIGTRAN suite of protocols
- Uses SCTP and IP as its underlying transport
- M3UA configurations available:
- MTP level 3 Backhaul: Dialogic® I-Gate® 4000 EDGE Media Gateway terminates MTP and user signaling is backhauled to the ControlSwitch System via IP
- Peering with M3UA-capable STPs; in this mode, the ControlSwitch System peers directly with STPs via IP
|
| Service Level Assurance/QoS | - Real-time event/statistics-driven routing and policy enforcement
- Programmable concurrent calls limitation and monitoring
- Prefixes, CIC, and TNS parameters
- ASR/ACD-based routing
- Statistics database and report
- Several report types (co-residing with the event relay server process and event collector)
- ASR reports
- ACD reports
|
Directory Services
| - Supports directory lookups and number translations natively
- Provides optimized large database-lookup solution for applications such as ANI screening, LNP, and ENUM
- Scales up to 400 million entries
|
| Legal Intercept | - Provides mediation device with two interfaces:
- TDM based loop via the Third Party Mediation Device for call delivery
- IP-based interface for provisioning of interception targets
|
Element Management
| - Unified management of distributed systems
- Web-based GUI with local and remote interfaces
- End-to-end real time call tracing capabilities for both PSTN and VoIP signaling
- Dynamic modification to parameters during operation
- Circuit-switch COT test support
- Configuration and provisioning of all ControlSwitch System elements, SS7 network parameters, trunk groups, media gateway parameters, routing policies, and dial plans
- Fault management
- ControlSwitch System alarm management, media gateway alarm management, network element monitoring, and SS7 monitoring and audit reports
- Open northbound interfaces for management system support
- PL-SQL API and SNMP
- Security
- Privilege levels and security for users
- Creation and deletion of user groups
- Login/logoff tracking
- Channel management at DS0 level
- ISUP, CAS, and PRI trunks resource management
- CDRs browsing
- Performance management:
- Periodic monitoring
- Scheduled reports generation
- Wide range of Call Setup and Trunk Usage reports
|
| CDR Generation and Searching | - FTP transport, text-based CDR with over 160 parameters, BAF format, Flexible CDR Query
- Generates text-based CDRs for billing mediation systems
- Raw call events for billing and traffic analysis
- Configurable persistent storage for call event data
- Generates Bellcore AMA Format (BAF) CDRs
- Coexistence with Open Settlement Protocol Clearinghouse
|
| Event Collection and Relay | - Collects and stores billing and call-related events and QoS statistics
- In conjunction with the Policy Element, automates network-wide, real-time feedback and corrective action to maintain custom SLAs
- SLAs established per customer, per interconnection partner, per service, etc.
- Filters and relays events to the clients in an open and standard format for:
- Easing the integration with the customized event processing
Monitoring and fraud management applications, etc.
|
| Protocol Support | - MGCP
- H.248 v1 and H248 v2
- ANSI/ITU/ETSI ISUP and many country variants
- AIN/INAP/MAP
- ISDN Q.931 (PRI): NI-2 and ETSI
- Back-up D channel support
- Q.931 non-facility associated signaling (NFAS)
- SIP (RFC 3261 and others)
- H.323 V1-V4
- SIGTRAN - SCTP, M3UA and IUA
- Digital CAS support (E&M, R1.5, R2)
- CAS MF and DTMF signaling support
- CAS wink start, immediate start, and delay dial
- SNMP
- OSP
|
| Recommended Platform | - NEBS Level 3 compliant Sun Netra platforms running Sun Solaris operating system
- Software runs on other SUN platforms running Sun Solaris operating system
|
Approval Compliances and Standards | - ITU
- ANSI
- ETSI
- Telcordia
- IETF
- TISPAN
- IMS
- MSF
|
| Installation and Configuration | - Pre-loaded and preconfigured on the system
- Supports software upgrades
|
Scalability and Performance
| - Scales to five million Busy Hour Call Attempts (BHCAs) across multiple media gateways on a SUN platform
- Distributed, modular architecture provides scalability through addition of SUN platforms
|
| Fault Tolerance and Reliability | - Automatic failover of any ControlSwitch System element to active backups distributed on one or more machines
- Auto-diagnostic and recovery mechanisms for any hardware, software, signaling link, or network fault
- SCTP - Protocol for messaging between ControlSwitch System elements and network level redundancy
- Events collector and CDR Manager disk mirroring
High availability - Geographic redundancy
- Routing database replication
- CPU overload protection
- SS7 link redundancy
|
| Approvals, Compliance, and Warranty | |
| Hazardous substances | |
| Country-specific approvals | - Contact your local Dialogic sales representative
|
| Warranty | - Contact your local Dialogic sales representative
|
